Name	Elevator Air Conditioner Components NO Water Drips Design
Product Type:	elevator parts
Availability:	5000pcs
Certificates:	ISO9001
Warranty-Time:	1 year
MOQ:	1pcs
Payment:	TT
Delivery time:	2-3 days after payment

60Hz Elevator Air Conditioner Refrigerant R410A

NO Water Drips Design

Part No.	ACR-HH-26Z	ACR-HH-D26Z	ACR-HH-26QZ	ACR-HH-D26QZ	ACR-HH-35QZ	ACR-HH-D35QZ
Rated Cooling Capacity(W)	2600	2600	2600	2600	3500	3500
Rated Heating Capacity(W)	/	2200	/	2200	/	2200
Air Flow (High/Low, m3/h )	430/340	430/340	430/340	430/340	550/440	550/440
Rated Cooling Input Current(A)	4.3	4.3	4.3	4.3	5.4	5.4
Rated Heating Input Current(A)	/	10	/	10	/	10.3
Rated Cooling Input Power(W)	950	950	950	950	1220	1220
Rated Heating Input Power(W)	/	2200	/	2200	/	2255
Noise dB (A)	＜53		＜53		＜55
Voltage/Frequency	220-230V~60Hz
Refrigerant	R410A
Water Proof Level	IPX4
Insulated Voltage Grade	I Grade
Compressor Protection	Overheat protection; Over current protection; Delay startup protection
Control Mode	Standard: Program control (automatically ) +infrared remote control (Manually) Remote control (automatically ) +infrared remote control (Manually) as an option at extra cost
Dimensions (L×W×H)mm	615×455×435	615×455×435	545×455×435	545×455×435	640×570×510
Weight(kg)	39.5	40	38.5	39	57	57.5
For Elevator Load Capacity(kg)	≤1350	≤1350	≤1350	≤1350	1350-1600
Air Out, Air Return	from bottom ,to bottom		from front, to front		from front ,to front
