| Name | Passenger Elevator Ventilation Fan Parts EVF-YS-ZQF330 |
| Product Type: | elevator parts |
| Availability: | 5000pcs |
| Certificates: | ISO9001 |
| Warranty-Time: | 1 year |
| MOQ: | 1pcs |
| Payment: | TT |
| Delivery time: | 2-3 days after payment |
Product Description
Elevator Cross Flow Fan
Elevator Ventilator
Elevator Ventilator Fan
Elevator Ventilation Fan
Elevator Ventilating Fan
Elevator Ventilation System
Elevator Axial Flow Fan
Elevator Axial Fan
Elevator Aerofoil Fan
Motor: Capacitor Induction
Ball Bearing: YES
Impeller: Reinforced Plastic, ø91mm*320mm
Frame: Steel with plastic-coated
Service Life: 30,000hours
Operation Temperature: -20℃- +50℃
Weight: 2.7kg
Part No. | Voltage(VAC) | Frequency(Hz) | Current(A) | Power(W) | Speed(RPM) | Air Flow(m3/hour) | Noise(dB) |
EVF-YS-ZQF330/100 | 100 | 50/60 | 0.23/0.26 | 24/27 | 1140/1060 | 300/265 | ≤47 |
EVF-YS-ZQF330/110 | 110 | 50/60 | 0.25/0.28 | 27/30 | 1170/1090 | 320/300 | ≤47 |
EVF-YS-ZQF330/127 | 127 | 50/60 | 0.22/0.25 | 28/31 | 1230/1260 | 345/345 | ≤47 |
EVF-YS-ZQF330/220 | 220 | 50/60 | 0.10/0.13 | 22/27 | 1240/1320 | 330/350 | ≤47 |
EVF-YS-ZQF330/230 | 230 | 50/60 | 0.10/0.13 | 23/28 | 1270/1350 | 340/360 | ≤47 |
1.The largest elevator parts company integrating warehousing with marketing.
2.Leading supplier and expoter in elevator parts industry.
3.We have various brands elevator parts,such as Kone,Otis,LG Sigma,Schindler,Toshiba,Thyssen and so on .
4.With the excellent after-saled service and warranty.
