NameNICE-CE1 Control Cabinet MONARCH Control Cabinet
Product Type:elevator parts
Availability:5000pcs
Certificates:ISO9001
Warranty-Time:1 year
MOQ:1pcs
Payment:TT
Delivery time:2-3 days after payment

Product Description

  • NICE-CE1 Control Cabinet

    Power18.5kW-30KW
    Speed≤4m/s
    Max. Number of LandingFloors40 filoors (can be extended)
    Witing  ModePlug-in
    Cabinat Dimensions (W*D*H)610*290*1170mm(The height of the resistance box is included)
    Cantrol SystermNICE3000new integrated controller
    Man-Machine Signal Sampling ModeAll serial
    Standard Applecatble Power SupplyThree-phase 380 VAC
    Brake Applied VoltageDC110V
    Applicabler Elevator TypeElevator with machine room
    Applicable MotorPMSM, AC asynchronous motor
    ColorGray RAL7032
    Sandard PackageCarton
    Mounting ModeFloor-type


    NICE3000new integrated controller


    The NICE3000new has the following advantages:
    1. It supports high-performance vector control and open-loop low speed running. It can drive both AC asynchronous motor and permanent magnetic synchronous motor (PMSM), and implement switchover between the two types of motors easily by modifying only one parameter.
    2. It supports direct parallel control and group control of two elevators, and supports the CANbus and Modbus communication protocols for remote monitoring, which reduces the required quantity of travling cables.
    3. It supports a maximum of 40 floors and is widely applied to elevators used in the residence, office buildings, shopping centers, and hospitals.
