Name | NICE-CF1 MONARCH Control Cabinet |
Product Type: | elevator parts |
Availability: | 5000pcs |
Certificates: | ISO9001 |
Warranty-Time: | 1 year |
MOQ: | 1pcs |
Payment: | TT |
Delivery time: | 2-3 days after payment |
Product Description
NICE-CF1 Control Cabinet
Power | 37kW-55KW |
Speed | ≤4m/s |
Max. Number of LandingFloors | 40 filoors (can be extended) |
Witing Mode | Plug-in |
Cabinat Dimensions (W*D*H) | 800*330*1426mm(The height of the resistance box is included) |
Cantrol Systerm | NICE3000new integrated controller |
Man-Machine Signal Sampling Mode | All serial |
Standard Applecatble Power Supply | Three-phase 380 VAC |
Brake Applied Voltage | DC110V |
Applicabler Elevator Type | Elevator with machine room |
Applicable Motor | PMSM, AC asynchronous motor |
Color | Gray RAL7032 |
Sandard Package | Carton |
Mounting Mode | Floor-type |
NICE3000new integrated controller
The NICE3000new has the following advantages:
1. It supports high-performance vector control and open-loop low speed running. It can drive both AC asynchronous motor and permanent magnetic synchronous motor (PMSM), and implement switchover between the two types of motors easily by modifying only one parameter.
2. It supports direct parallel control and group control of two elevators, and supports the CANbus and Modbus communication protocols for remote monitoring, which reduces the required quantity of travling cables.
3. It supports a maximum of 40 floors and is widely applied to elevators used in the residence, office buildings, shopping centers, and hospitals.
