| Name | NICE-CX1 Control Cabinet MONARCH Control Cabinet |
| Product Type: | elevator parts |
| Availability: | 5000pcs |
| Certificates: | ISO9001 |
| Warranty-Time: | 1 year |
| MOQ: | 1pcs |
| Payment: | TT |
| Delivery time: | 2-3 days after payment |
Product Description
NICE-CX1 Control Cabinet
| Power | 2.2kW-7.5KW |
| Speed | ≤1m/s |
| Witing Mode | Plug-in |
| Cabinat Dimensions (W*D*H) | 530*240*854mm(The height of the resistance box is included) |
| Cantrol Systerm | NICE3000new integrated controller |
| Man-Machine Signal Sampling Mode | All serial |
| Standard Applecatble Power Supply | Single-phase 220VAC, thee-phase 220VAC, Three-phase 380 VAC |
| Brake Applied Voltage | DC110V |
| Applicabler Elevator Type | Home Elevator |
| Applicable Motor | PMSM adaptable with PG cardol PG-E type |
| Color | Dark gray with orange peel SC02024 |
| Sandard Package | Carton |
| Mounting Mode | Floor-type, wall-mounting type |
NICE3000new integrated controller
The NICE3000new has the following advantages:
1. It supports high-performance vector control and open-loop low speed running. It can drive both AC asynchronous motor and permanent magnetic synchronous motor (PMSM), and implement switchover between the two types of motors easily by modifying only one parameter.
2. It supports direct parallel control and group control of two elevators, and supports the CANbus and Modbus communication protocols for remote monitoring, which reduces the required quantity of travling cables.
3. It supports a maximum of 40 floors and is widely applied to elevators used in the residence, office buildings, shopping centers, and hospitals.
1.The largest elevator parts company integrating warehousing with marketing.
2.Leading supplier and expoter in elevator parts industry.
3.We have various brands elevator parts,such as Kone,Otis,LG Sigma,Schindler,Toshiba,Thyssen and so on .
4.With the excellent after-saled service and warranty.
