| Name | OMRON Elevator Relay G7SA-3A1B DC24V Spare Parts |
| Product Type: | lifts spare part |
| Availability: | 5000pcs |
| Certificates: | ISO9001 |
| Warranty-Time: | 1 year |
| MOQ: | 1pcs |
| Payment: | TT |
| Delivery time: | 2-3 days after payment |
Product Description
Model Number Legend
Main unit Relays with forcibly guided contacts
G7SA-□A□B□
1 2 3
Relays use PCB terminals. This allows for mounting on PCBs and for connection to optional dedicated sockets (order separately).
Specify the power supply voltage (coil rated voltage) when ordering.
| 1. NO Contact Poles | 2. NC Contact Poles | 3. Coil Rated Voltage (V) |
| 2:DPST-NO | 1: SPST-NC | 12 VDC |
| 3:3PST-NO | 2: DPST-NC | 18 VDC |
| 4:4PST-NO | 3: 3PST-NC | 21 VDC |
| 5:5PST-NO | 24 VDC | |
| 48 VDC | ||
| 110 VDC |
Ratings Safety Relay Unit Coil (4 poles)
| Item Rated voltage | Rated current (mA) | Coil resistance (LI) | Max. voltage (V) | Power consumption (mW) |
| 12 VDC | 30 | 400 | 110% | Approx. 360 |
| 18 VDC | 20 | 900 | ||
| 21 VDC | 17.1 | 1,225 | ||
| 24 VDC | 15 | 1,600 | ||
| 48 VDC | 7.5 | 6,400 | ||
| 110 VDC | 3.8 | 28,810 | Approx. 420 |
Ratings Safety Relay Unit Coil (6 poles)
| Item Rated voltage | Rated current (mA) | Coil resistance (LI) | Max. voltage (V) | Power consumption (mW) |
| 12 VDC | 41.7 | 288 | 110% | Approx. 500 |
| 18 VDC | 27.8 | 648 | ||
| 21 VDC | 23.8 | 882 | ||
| 24 VDC | 20.8 | 1,152 | ||
| 48 VDC | 10.4 | 4,606 | ||
| 110 VDC | 5.3 | 20,862 | Approx. 580 |
Contacts
| Item Load | Resistive load |
| Rated load | 6 A at 250 VAC, 6 A at 30 VDC |
| Rated carry current | 6 A |
| Max. switching voltage | 250 VAC, 125 VDC |
| Max. switching current | 6 A |
| Contact materials | Au plating + Ag alloy |
1.The largest elevator parts company integrating warehousing with marketing.
2.Leading supplier and expoter in elevator parts industry.
3.We have various brands elevator parts,such as Kone,Otis,LG Sigma,Schindler,Toshiba,Thyssen and so on .
4.With the excellent after-saled service and warranty.
