PRODUCT CATALOG

NameElevator Components Overspeed Governor OX-240 Spare Parts
Product Type:elevator component
Availability:6000pcs
Certificates:ISO9001
Warranty-Time:1 year
MOQ:1pcs
Payment:TT
Delivery time:2-3 days after payment

Product Description

  • Base plate: This speed limiter standard with no installation base
    Rated speed:≤0.63m/s 1.0m/s 1.5-1.6m/s 1/75m/s
    Suitable installation location: Car side or counterweight side
    Sheave diameter: diameter Ф200mm
    Governor rope: Ф6mm
    Electric connection: Governor action switch connect safety circuit



    Parameter for various type of governor


    NO.

    MODEL

    RATED SPEED

    ROPE WHEEL

    GOVERNOR ROPE

    TENSION DEVICE

    1

    OX-240

    ≤2.5

    Ф240

    Ф6/Ф8/Ф6.3

    OX-300

    2

    OX-240A

    ≤1.75

    Ф240

    Ф6/Ф8/Ф6.3

    OX-300

    3

    OX-240B

    ≤2.5

    Ф240

    Ф6/Ф8/Ф6.3

    OX-300

    4

    OX-240E

    ≤0.63

    Ф240

    Ф6/Ф8/Ф6.3

    OX-300

    5

    OX-240F

    ≤2.5

    Ф240

    Ф6/Ф8/Ф6.3

    OX-300

    6

    OX-187

    ≤1.0

    Ф200

    Ф6/Ф6.3

    OX-200

    Ф240Ф6/Ф8/Ф6.3

    ≤1.75

    Ф240Ф6/Ф8/Ф6.3

    7

    OX-186

    ≤0.63

    Ф200

    Ф6

    OX-100

    8

    OX-186A

    ≤0.4

    Ф150

    Ф6

    OX-100A

    9

    OX-208

    ≤1.75

    Ф200

    Ф6


    10

    OX-208A

    ≤1.75

    Ф200

    Ф6


    11

    OX-001

    ≤0.63

    Ф280

    Ф8
