| Name | Elevator Components T Type Guide Rail Spare Parts |
| Product Type: | elevator parts |
| Availability: | 5000pcs |
| Certificates: | ISO9001 |
| Warranty-Time: | 1 year |
| MOQ: | 1pcs |
| Payment: | TT |
| Delivery time: | 2-3 days after payment |
Product Description
FUJILF T Type Elevator Guide Rails With Different Sizes , SPEC(mm) 82.5*68.25*9 , FUJILF-GR-T Serices
| Parameter | b1 | h1 | h | k | n | c | g | m1 | m2 | t1 | t2 |
| Tolerance | ±1.5 | ±0.75 | ±0.1 | ±0.1 | 3 | ±0.75 | ±0.06 | 0 | ±0.1 | ±0.1 | |
| FUJILF-Type | ±1.52 | ±0.08 | ±0.08 | ±0.08 | 0 | ±0.6 | 0 | -0.06 | ±0.08 | ±0.08 | |
| GR-T70A | 69.85 | 50.2412 | 49.1998 | 15.875 | 25.4 | 9.525 | 7.9 | 6.4008 | 6.3754 | 7.1374 | 6.35 |
| GR-T70B | 70 | 65 | 64 | 9 | 34 | 6 | 6 | 3 | 2.95 | 3.5 | 3 |
| GR-T82 | 82.5 | 68.3 | 66.6 | 9 | 25.4 | 7.5 | 6 | 3 | 2.95 | 3.5 | 3 |
| GR-T75 | 75 | 62 | 61 | 10 | 30 | 8 | 7 | 3 | 2.95 | 3.5 | 3 |
| GR-T78 | 78 | 56 | 55 | 10 | 25 | 8 | 7 | 3 | 2.95 | 3.5 | 3 |
| GR-T89 | 89 | 62 | 61 | 15.9 | 33.4 | 10 | 7.9 | 6.4 | 6.37 | 7.14 | 6.35 |
| GR-T90 | 90 | 75 | 74 | 16 | 42 | 10 | 8 | 6.4 | 6.37 | 7.14 | 6.35 |
| GR-T114 | 114 | 89 | 88 | 16 | 38 | 10 | 8 | 6.4 | 6.37 | 7.14 | 6.35 |
| GR-T127 | 127 | 88.9 | 88 | 15.9 | 44.5 | 10 | 7.9 | 6.4 | 6.37 | 7.14 | 6.35 |
| GR-T127 | 127 | 88.9 | 88 | 15.9 | 50.8 | 10 | 12.7 | 6.4 | 6.37 | 7.14 | 6.35 |
| GR-T140A | 140 | 108 | 107 | 19 | 50.8 | 12.7 | 12.7 | 6.4 | 6.37 | 7.14 | 6.35 |
| GR-T140B | 140 | 102 | 101 | 28.6 | 50.8 | 17.5 | 14.5 | 6.4 | 6.37 | 7.14 | 6.35 |
| GR-T140C | 140 | 127 | 126 | 31.8 | 57.2 | 19 | 17.5 | 6.4 | 6.37 | 7.14 | 6.35 |
1.The largest elevator parts company integrating warehousing with marketing.
2.Leading supplier and expoter in elevator parts industry.
3.We have various brands elevator parts,such as Kone,Otis,LG Sigma,Schindler,Toshiba,Thyssen and so on .
4.With the excellent after-saled service and warranty.
