Name	50Hz Elevator Parts Air Conditioner Refrigerant R410A
Product Type:	elevator parts
Availability:	5000pcs
Certificates:	ISO9001
Warranty-Time:	1 year
MOQ:	1pcs
Payment:	TT
Delivery time:	2-3 days after payment

50Hz Elevator Air Conditioner Refrigerant R410A

Part No.	ACR-HH-26	ACR-HH-D26	ACR-HH-26Q	ACR-HH-D26Q	ACR-HH-35Q	ACR-HH-D35Q
Rated Cooling Capacity(W)	2600	2600	2600	2600	3500	3500
Rated Heating Capacity(W)	/	2200	/	2200	/	2200
Air Flow (High/Low, m3/h )	400/330	400/330	400/330	400/330	570/450	570/450
Rated Cooling Input Current(A)	4.3	4.3	4.3	4.3	5.8	5.8
Rated Heating Input Current(A)	/	10	/	10	/	10.3
Rated Cooling Input Power(W)	930	930	930	930	1250	1250
Rated Heating Input Power(W)	/	2200	/	2200	/	2270
Noise dB (A)	<53		<53		<55
Voltage/Frequency	AC220-230V ~ 50Hz
Refrigerant	R410A
Water Proof Level	IPX4
Insulated Voltage Grade	I Grade
Compressor Protection	Overheat protection; Over current protection; Delay startup protection
Control Mode	Standard: Program control (automatically ) +infrared remote control (Manually) Remote control (automatically ) +infrared remote control (Manually) as an option at extra cost
Dimensions (L×W×H)mm	615×455×435		545×455×435		640×570×510
Weight(kg)	40	40.5	39	39.5	57	57.5
For Elevator Load Capacity(kg)	≤1350		≤1350		＞1350
Air Out, Air Return	from bottom ,to bottom		from front, to front		from front ,to front
