MRL KONE Elevator Gearless Traction Machine

KONE MX10 Machine Replacer

NEW ARRIVAL

Permanent Magnet Synchronous Motor with NdFeB Magnets

Slim Design, Ultra Thin Design, Ultra Slim Design

Mounting Dimension: same as KONE MX10 Motors,

Perfect Compatibility: can be replaced directly

High Efficiency

Axle Load: up to 3,000 kg

Replaceable Traction Sheave

Separately controllable brake circuits

Type Test Approval

With UCPM (Unintended Car Movement Protection System)

With ACOP(Ascending Car Overspeed Protection)

Temperature monitoring by PTC thermistor

Rail Installation Available: YES

Brake System: CE Approval

Traction Sheave Diameter: ø480mm

Rope Guard: EN81 Approval

Motor Cable Length: 5 m, 10 m, 15 m, 20 m and 25 m

Mechanical manual operation brake release system (Brake release wire)

Roping 2:1

Capacity: 1000kg, 1150kg

Speed: 1m/s | 1.75m/s | 2.0m/s | 2.5m/s

Power Supply: AC380V

Sheave: ø480mm *6*ø8mm | ø480mm*5*ø10mm

Brake Starting Voltage: DC200V

Brake Maintaining Voltage: DC110V

Matching Inverter: Monarch | STEP | KONE KDM & KDL Inverter

Weight: 370kg
