Name | Freight Elevator Geared Machine Spare Parts |
Product Type: | elevator component |
Availability: | 6000pcs |
Certificates: | ISO9001 |
Warranty-Time: | 1 year |
MOQ: | 1pcs |
Payment: | TT |
Delivery time: | 2-3 days after payment |
Product Description
Cargo Elevator Geared Machine, Freight elevator geared machine, goods elevator geared machine
Roping 1:1, Capacity 1000kg, Speed 1m/s, 11kW, AC380V, 25A, Sheave Dia. 610mm, 5*13*20
Roping 2:1, Capacity 2000kg, Speed 0.5m/s, 11kW, AC380V, 25A, Sheave Dia. 610mm, 5*13*20
Machine Arrangement: Right Hand | Left Hand
Control: VVVF
Standard Machine is coming with encoder
Roping 2:1, Capacity 2000kg, Speed 1m/s, 22kW, AC380V, 41A, Sheave Dia. 650mm, 5*13*20
Roping 4:1, Capacity 4000kg, Speed 0.5m/s, 22kW, AC380V, 41A, Sheave Dia. 650mm, 8*13*20
Roping 2:1, Capacity 3000kg, Speed 1m/s, 30kW, AC380V, 59A, Sheave Dia. 650mm, 8*13*20
Roping 4:1, Capacity 5000kg, Speed 0.5m/s, 26kW, AC380V, 50A, Sheave Dia. 610mm, 8*13*20
Roping 1:1, Capacity 1600kg, Speed 1m/s, 15kW, AC380V, 32A, Sheave Dia. 610mm, 8*13*20
Roping 2:1, Capacity 3000kg, Speed 0.5m/s, 15kW, AC380V, 32A, Sheave Dia. 610mm, 8*13*20
Roping 4:1, Capacity 4000kg, Speed 0.25m/s, 15kW, AC380V, 32A, Sheave Dia. 650mm, 8*13*20
Roping 4:1, Capacity 5000kg, Speed 0.25m/s, 15kW, AC380V, 32A, Sheave Dia. 650mm, 8*13*20
Machine Arrangement: Right Hand | Left Hand
Control: VVVF
Standard Machine is coming with encoder
Roping 1:1, Capacity 2500kg, Speed 2m/s, 45kW, AC380V, 87A, Sheave Dia. 800mm, 8*16*25
Roping 2:1, Capacity 5000kg, Speed 1m/s, 45kW, AC380V, 87A, Sheave Dia. 800mm, 8*16*25
Roping 4:1, Capacity 10000kg, Speed 0.5m/s, 45kW, AC380V, 87A, Sheave Dia. 800mm, 8*16*25
Machine Arrangement: Right Hand | Left Hand
Control: VVVF
Standard Machine is coming with encoder
1.The largest elevator parts company integrating warehousing with marketing.
2.Leading supplier and expoter in elevator parts industry.
3.We have various brands elevator parts,such as Kone,Otis,LG Sigma,Schindler,Toshiba,Thyssen and so on .
4.With the excellent after-saled service and warranty.
