| Name | Passenger Elevator Ventilating Fan Spare Parts |
| Product Type: | elevator parts |
| Availability: | 5000pcs |
| Certificates: | ISO9001 |
| Warranty-Time: | 1 year |
| MOQ: | 1pcs |
| Payment: | TT |
| Delivery time: | 2-3 days after payment |
Product Description
Elevator Cross Flow Fan
Elevator Ventilator
Elevator Ventilator Fan
Elevator Ventilation Fan
Elevator Ventilating Fan
Elevator Ventilation System
Elevator Axial Flow Fan
Elevator Axial Fan
Elevator Aerofoil Fan
Motor: Capacitor Induction
Sleeve or Ball Bearing
Impeller: Reinforced Plastic, ø91mm*260mm
Frame: Steel with Electroplate
Service Life: 10,000hours with Sleeve bearing, 30,000hours with ball bearing
Operation Temperature: -20℃- +50℃
Weight: 2.6kg
Part No. | Voltage(VAC) | Frequency(Hz) | Current(A) | Power(W) | Speed(RPM) | Air Flow(m3/hour) | Noise(dB) |
EVF-YS-ZFB9B/100 | 100 | 50/60 | 0.21/0.23 | 22/25 | 1200/1250 | 245/260 | ≤47 |
EVF-YS-ZFB9B /110 | 110 | 50/60 | 0.23/0.25 | 24/27 | 1250/1300 | 255/270 | ≤47 |
EVF-YS-ZFB9B /220 | 220 | 50/60 | 0.09/0.10 | 21/24 | 1260/1370 | 250/260 | ≤47 |
EVF-YS-ZFB9B /230 | 230 | 50/60 | 0.09/0.11 | 21/25 | 1300/1420 | 260/280 | ≤47 |
Part No. | Voltage(VAC) | Frequency(Hz) | Current(A) | Power(W) | Speed(RPM) | Air Flow(m3/hour) | Noise(dB) |
EVF-YS-ZFB9D/100 | 100 | 50/60 | 0.21/0.23 | 22/25 | 1200/1250 | 245/260 | ≤47 |
EVF-YS-ZFB9D/110 | 110 | 50/60 | 0.23/0.25 | 24/27 | 1250/1300 | 255/270 | ≤47 |
EVF-YS-ZFB9D/220 | 220 | 50/60 | 0.09/0.10 | 21/24 | 1260/1370 | 250/260 | ≤47 |
EVF-YS-ZFB9D/230 | 230 | 50/60 | 0.09/0.11 | 21/25 | 1300/1420 | 260/280 | ≤47 |
