| Name | Elevator traction machine GTW10 Spare Parts |
| Product Type: | elevator component |
| Availability: | 6000pcs |
| Certificates: | ISO9001 |
| Warranty-Time: | 1 year |
| MOQ: | 1pcs |
| Payment: | TT |
| Delivery time: | 2-3 days after payment |
Product Description
| Suspension:2:1 | LiftSpeed(m/s) | ||||||||||
| Load(kg) | 0.63 | 0.75 | 1 | 1.5 | 1.6 1.75 | 2 | 2.5 | ||||
| 320 | GTW7A | ||||||||||
| 450 | |||||||||||
| 550 | |||||||||||
| 630 | GTW7A | GTW7A、GTW9S、GTW2S | GTW9S | ||||||||
| 800 | GTW9S、GTW2S | ||||||||||
| 1000 | GTW2S、GTW9S、GTW10M | GTW9S、GTW10M、GTW10L | GTW10M、GTW1OL| | ||||||||
| 1150 | GTW2S、GTW3、GTW9S、GTW10M | ||||||||||
| 1250 | GTW3、GTW10M、GTW10L | GTW10M、GTW1OL | |||||||||
| 1350 | GTW3、GTW5A、GTW10、GTW10L | GTW5A、GTW10、GTW10L | GTW10、GTW10L | ||||||||
| 1600 | GTWSA、GTW10、GTW1OL | ||||||||||
| 2000 | GTW5A、GTW10L | GTW10L | |||||||||
| 2250 | GTW10L | ||||||||||
Elevator traction machine GTW10
| SANJIN-Spec | Load (kg) | Lift Speed (m/s) | Sheave Diam(mm) | RopeSheave (mm) | Current (A) | Torque (Nm) | Rated Speed (rpm) | Frequency (Hz) | Power (kW) |
| GTW10-131P0 | 1350 | 1 | φ485 | 8xφ10x16 | 19.3 | 1070 | 79 | 21.1 | 8.9 |
| GTW10-131P5 | 1350 | 1.5 | φ485 | 8xφ10x16 | 29.5 | 1070 | 118 | 31.5 | 13.2 |
| GTW10-131P6 | 1350 | 1.6 | φ485 | 8xφ10x16 | 29.5 | 1070 | 126 | 33.6 | 14. |
| GTWIO-131P7 | 1350 | 1.75 | φ485 | 8xφ10x16 | 32.2 | 1070 | 138 | 36.8 | 15.5 |
| GTW10-132P0 | 1350 | 2 | φ485 | 8xφ10x16 | 37 | 1070 | 158 | 42.1 | 17.7 |
| GTW10-132P5 | 1350 | 2.5 | φ485 | 8xφ10x16 | 45.8 | 1070 | 197 | 52.5 | 22.1 |
| GTW10-161P0 | 1600 | 1 | φ485 | 8xφ10x16 | 22.8 | 1270 | 79 | 21.1 | 10.5 |
| GTW1O-161P5 | 1600 | 1.5 | φ485 | 8xφ10x16 | 35.6 | 1270 | 118 | 31.5 | 15.7 |
| GTW10-161P6 | 1600 | 1.6 | φ485 | 8xφ10x16 | 35.6 | 1270 | 126 | 33.6 | 16.8 |
| GTWIO-161P7 | 1600 | 1.75 | φ485 | 8xφ10x16 | 38.7 | 1270 | 138 | 36.8 | 18.4 |
| GTW10-162P0 | 1600 | 2 | φ485 | 8xφ10x16 | 44.5 | 1270 | 158 | 42.1 | 21 |
| GTW10-162P5 | 1600 | 2.5 | φ485 | 8xφ10x16 | 55.7 | 1270 | 197 | 52.5 | 26.2 |
| GTW10-81P0-1 | 800 | 1 | φ485 | 8xφ10x16 | 12.5 | 1270 | 39 | 10.4 | 5.2 |
| GTW1IO-81P5-1 | 800 | 1.5 | φ485 | 8xφ10x16 | 19.3 | 1270 | 59 | 15.7 | 7.8 |
| GTW10-81P6-1 | 800 | 1.6 | φ485 | 8xφ10x16 | 19.3 | 1270 | 63 | 16.8 | 8.4 |
| GTW1O-81P7-1 | 800 | 1.75 | φ485 | 8xφ10x16 | 20.6 | 1270 | 69 | 18.4 | 9.2 |
| GTW10-82P0-1 | 800 | 2 | φ485 | 8xφ10x16 | 23.5 | 1270 | 79 | 21.1 | 10.5 |
| GTW1O-82P5-1 | 800 | 2.5 | φ485 | 8xφ10x16 | 28.9 | 1270 | 99 | 26.4 | 13.2 |
