| Name | Toshiba Elevator Deflector Sheave 440-480 |
| Product Type: | elevator spareparts |
| Availability: | 5000pcs |
| Certificates: | ISO9001 |
| Warranty-Time: | 1 year |
| MOQ: | 1pcs |
| Payment: | TT |
| Delivery time: | 2-3 days after payment |
Product Description
Nylon Deflector Sheave,
Elevator Pulley Sheave,
Lift Sheave,
Deflective Sheave
1.Nylon types
2.Dia 240-640mm
3.Shaft Length and Diameter as Request
FUJILF elevator deflector sheave Model
| FUJILF-Model | Diameter | Aperture | Number of slots | Rope | Slot Pitch | Thickness | Thickness | Rated load | Bearing |
| D | E | N | d | P | H | h | Q |
| SANJIN-440-01 | φ440 | φ110 | 3 | 10 | 15 | 60 | 80 | ≤1000KG | 6212 |
| SANJIN-440-02 | 3 | 10 | 16 | ||||||
| SANJIN-440-03 | 4 | 8 | 12 | ||||||
| SANJIN-440-04 | 4 | 8 | 13 | ||||||
| SANJIN-440-05 | φ130 | 4 | 10 | 15 | 72 | 95 | ≤1600KG | 6312 | |
| SANJIN-440-06 | 4 | 10 | 16 | ||||||
| SANJIN-440-07 | 5 | 8 | 12 | ||||||
| SANJIN-440-08 | 5 | 8 | 13 | ||||||
| SANJIN-440-09 | 5 | 10 | 15 | 90 | 95 | ||||
| SANJIN-440-10 | 5 | 10 | 16 | ||||||
| SANJIN-440-11 | 6 | 8 | 12 | ||||||
| SANJIN-440-12 | 6 | 8 | 13 | ||||||
| SANJIN-440-13 | φ140 | 6 | 10 | 15 | 105 | 95 | ≤2000KG | 6313 | |
| SANJIN-440-14 | 6 | 10 | 16 | ||||||
| SANJIN-440-15 | 7 | 8 | 12 | ||||||
| SANJIN-440-16 | 7 | 8 | 13 | ||||||
| SANJIN-480-01 | φ480 | φ110 | 3 | 10 | 15 | 60 | 80 | ≤1000KG | 6212 |
| SANJIN-480-02 | 3 | 10 | 16 | ||||||
| SANJIN-480-03 | 4 | 8 | 12 | ||||||
| SANJIN-480-04 | 4 | 8 | 13 | ||||||
| SANJIN-480-05 | φ130 | 4 | 10 | 15 | 72 | 95 | ≤1600KG | 6312 | |
| SANJIN-480-06 | 4 | 10 | 16 | ||||||
| SANJIN-480-07 | 5 | 8 | 12 | ||||||
| SANJIN-480-08 | 5 | 8 | 13 | ||||||
| SANJIN-480-09 | 5 | 10 | 15 | 90 | 95 | ||||
| SANJIN-480-10 | 5 | 10 | 16 | ||||||
| SANJIN-480-11 | 6 | 8 | 12 | ||||||
| SANJIN-480-12 | 6 | 8 | 13 | ||||||
| SANJIN-480-13 | φ140 | 6 | 10 | 15 | 105 | 95 | ≤2000KG | 6313 | |
| SANJIN-480-14 | 6 | 10 | 16 | ||||||
| SANJIN-480-15 | 7 | 8 | 12 | ||||||
| SANJIN-480-16 | 7 | 8 | 13 |
1.The largest elevator parts company integrating warehousing with marketing.
2.Leading supplier and expoter in elevator parts industry.
3.We have various brands elevator parts,such as Kone,Otis,LG Sigma,Schindler,Toshiba,Thyssen and so on .
4.With the excellent after-saled service and warranty.
