| Name | Toshiba Elevator Deflector Sheave 520-640 |
| Product Type: | elevator spareparts |
| Availability: | 5000pcs |
| Certificates: | ISO9001 |
| Warranty-Time: | 1 year |
| MOQ: | 1pcs |
| Payment: | TT |
| Delivery time: | 2-3 days after payment |
Product Description
Nylon Deflector Sheave,
Elevator Pulley Sheave,
Lift Sheave,
Deflective Sheave
1.Nylon types
2.Dia 240-640mm
3.Shaft Length and Diameter as Request
FUJILF elevator deflector sheave Model
| FUJILF-Model | Diameter | Aperture | Number of slots | Rope | Slot Pitch | Thickness | Thickness | Rated load | Bearing |
| D | E | N | d | P | H | h | Q |
| 520-01 | φ520 | φ130 | 3 | 13 | 20 | 70 | 95 | ≤1000KG | 6312 |
| 520-02 | 4 | 10 | 15 | ||||||
| 520-03 | 4 | 10 | 16 | ||||||
| 520-04 | 4 | 13 | 20 | 90 | 95 | ||||
| 520-05 | 5 | 10 | 15 | ||||||
| 520-06 | 5 | 10 | 16 | ||||||
| 520-07 | 5 | 13 | 20 | 108 | 95 | ≤1600KG | 6312 | ||
| 520-08 | 6 | 10 | 15 | ||||||
| 520-09 | 6 | 10 | 16 | ||||||
| 520-10 | φ140 | 6 | 13 | 20 | 128 | 120 | ≤2000KG | 6313 | |
| 520-11 | 7 | 10 | 15 | ||||||
| 520-12 | 7 | 10 | 16 | ||||||
| 520-13 | φ150 | 8 | 13 | 20 | 168 | 148 | ≤3000KG | 6314 | |
| 520-14 | 10 | 10 | 15 | ||||||
| 520-15 | 10 | 10 | 16 | ||||||
| 640-01 | φ640 | φ160 | 5 | 16 | 25 | 132 | 120 | ≤3000KG | 6315 |
| 640-02 | 6 | 13 | 20 | ||||||
| 640-03 | φ170 | 6 | 16 | 25 | 160 | 140 | ≤5000KG | 6316 | |
| 640-04 | 7 | 13 | 20 |
1.The largest elevator parts company integrating warehousing with marketing.
2.Leading supplier and expoter in elevator parts industry.
3.We have various brands elevator parts,such as Kone,Otis,LG Sigma,Schindler,Toshiba,Thyssen and so on .
4.With the excellent after-saled service and warranty.
