| Name | QMA Elevator Inverter Q-7000-EC QMA |
| Product Type: | elevator component |
| Availability: | 6000pcs |
| Certificates: | ISO9001 |
| Warranty-Time: | 1 year |
| MOQ: | 1pcs |
| Payment: | TT |
| Delivery time: | 2-3 days after payment |
Product Description
Q7000-EC Features
1.Type of FC: Adopt IGBT a PWM control
2.Control modes: Current vector control V/F control
3.W/functions such as connection-point-memory & DC 0~10V EASY TUNING, loading compensation for start-up torque, and manual vernier-adjustment correct
4.With high-performance safety function, 300% torque compensation, monitor the inverter torque compensation output at any time
5.With dynamic and static motor parameter self-learning (EASY TUNING) function.
6.The whole series complies with GB regulations and includes a brake unit.
7.W/speed feedback unit
| Inverter special for escalator Q7000-EC | ||||||||||
| FUJILF-model Q7000-EC | 0544 | 0744 | 1144 | 1544 | 1844 | 2244 | 3044 | 3744 | 4544 | |
| Rated output | Horsepower volume(HP) | 7 | 10 | 15 | 20 | 25 | 30 | 40 | 50 | 60 |
| Rated power(KW) | 5.5 | 7.5 | 11 | 15 | 18.5 | 22 | 30 | 37 | 45 | |
| Rated current(A) | 14 | 18 | 27 | 34 | 41 | 48 | 60 | 80 | 96 | |
| Output voltage(v) | Three phase 380/415/440/480 | |||||||||
| Output MAX. Frequency(Hz) | 400 | |||||||||
| power supply | Rated voltage and Frequency | Three phase 380v-480v,50/60Hz | ||||||||
| Permissible voltage fluctuation | +10%,-15% | |||||||||
| Permissible Frequency fluctuation | ± 5% | |||||||||
