Specifications：

Design No.: EEV25580AL3
Part Name:AT400/AT400R Lift Door Controller System
Specification: AT400
AT400R Lift door controller system, AT400 Lift door controller system

AT400R Lift door controller system:

SW Version for Application: A1131274AAD (V1.20) (2009-04-30)
SW Version for Loader Slave AAA31275AAA (V1.02) (2007-08-28)
AT400R Lift door controller system
Motor Model:AAA24350BL5 / BL6 (30VDC, 15A Peak. 4A Nom.)
Controller Model: AAA25580AL3 (2009-05-04)
(DC 120V Version, 120VDC/3A)
Siemens P/N A2B00063566
Hardware Rev.: 2008-03-31 (ES05)


AT400 Lift door controller system

SW Version AAA30967AAA, ATYYV0336.HEX
AT400 Lift door controller system
Motor model: AAA24350BL (30VDC, 15A Peak. 4A Nom.)
Controller Model: AAA25580AL4 (2008-1-29)
(MDLW Version, 17Vrms/5A)
21831A1 8009
Siemens P/N 10013673
Hardware Rev.2003-9-26
SW Version AAA30968AAA  CPUC_V15.HEX
Power Unit Model AAA621BF
230VAC  60Hz, 1.6A
110VAC  60Hz, 3.3A
88VAC   60Hz, 4A
