Name | Elevator Travelling Cable Elevator Cable TVVBP Spare Parts |
Product Type: | elevator component |
Availability: | 5000pcs |
Certificates: | ISO9001 |
Warranty-Time: | 1 year |
MOQ: | 1pcs |
Payment: | TT |
Delivery time: | 2-3 days after payment |
Product Description
FUJILF TVVBP 24x0.75+2x2Px0.75
Purposes: | Use for wiring of elevaRog control ciecles |
Characrereistic: | PVC Insulation, PVC sheath |
Rated voltage AC300/500V, Rated temperature 70°, Communication cable tie screen | |
Product standard: | GB5023.6-1997/227 IEC 71 F(TVVB)/60227 IEC71 F(TVVB) |
FUJILF TVVBP 24x0.75+2x2Px0.75 Strucrure and schematic drawing
Cores | Cores secrional area (㎡) | Conductor structure | Ourer Dimension (Max) |
24 | 24x.075 | 24x30/0.18 | 48.0x9.5 |
30 | 30x.075 | 30x30/0.18 | 53.0x9.5 |
36 | 36x0.75 | 36x30/0.18 | 57.0x9.5 |
40 | 40x0.75 | 40x30/0.18 | 56.0x9.5 |
48 | 48x0.75 | 48x30/0.18 | 70.0x9.5 |
60 | 60X0.75 | 60x30/0.18 | 82.0.x9.5 |
1.The largest elevator parts company integrating warehousing with marketing.
2.Leading supplier and expoter in elevator parts industry.
3.We have various brands elevator parts,such as Kone,Otis,LG Sigma,Schindler,Toshiba,Thyssen and so on .
4.With the excellent after-saled service and warranty.
