| Name | Schneider Emergency Stop Switch ZB2 BE102C Spare Parts |
| Product Type: | escalator spareparts |
| Availability: | 5000pcs |
| Certificates: | ISO9001 |
| Warranty-Time: | 1 year |
| MOQ: | 1pcs |
| Payment: | TT |
| Delivery time: | 2-3 days after payment |
Product Description
Characteristics: ZB2BE102 CONTACT BLOCK
ZB2-BE102: Single contact block, silver alloy, screw clamp terminal, 1 NC
ZBY9320: Legend holder 060 for emergency stop, plastic, yellow, marked EMERGENCY STOP
product or component type
Emergency switching off push-button
Emergency stop push-button
| Main | Complementary | |
| Range of product： Harmony XAC | Connections – terminals | Screw clamps terminals, 1 x 2.5 mm² with or without cable end |
| Product or component type ：Contact block | Screw clamps terminals, 2 x 1.5 mm² with or without cable end | |
| Component name： ZB2 | Mechanical durability | 1000000 cycles |
| Electrical circuit type： Control circuit | Contact code designation | A600 AC-15, Ue = 240 V, Ie = 3 A conforming to IEC 947-5-1 appendix A |
| Contact block application ：Single speed | A600 AC-15, Ue = 600 V, Ie = 1.2 A conforming to IEC 947-5-1 appendix A | |
| Contact block type ：Single | Q600 DC-13, Ue = 250 V, Ie = 0.27 A conforming to IEC 947-5-1 appendix A | |
| Type of operator ：Spring return | Q600 DC-13, Ue = 600 V, Ie = 0.1 A conforming to IEC 947-5-1 appendix A | |
| Product compatibility： XACA，XB4，XB5 | ||
| Contacts type and composition： 1 NC | ||
| Mounting of block ：Front mounting | ||
| Contact operation ：Slow-break | ||
