FCU0740 thin light curtain series
The number of Beam:40 beam of non-parallel beam
The number of Sensors:18 pairs
Sensor interval :106mm
Response time: less than 100 ms
Detection range: 1000 ~ 3000mm (static)
Anti-light intensity: 50000lux
Angle allows: plus or minus 10 °
Installation tolerance: 10mm vertical ~~-4mm level
Operating voltage: 18 ~ 30V DC
Current consumption: less than 100mA RMS
IP rating: IP54
Operating temperature range: 0 ° to 70 °
Storage temperature range: negative 40 ° to the positive 80 °
Dimensions: 9 * 26.5 * 2010mm
Cable length: 2.7 m
Safety Certification: UL. CUL. CE (EMC)

1.The largest elevator parts company integrating warehousing with marketing.

2.Leading supplier and expoter in elevator parts industry.

3.We have various brands elevator parts,such as Kone,Otis,LG Sigma,Schindler,Toshiba,Thyssen and so on .

4.With the excellent after-saled service and warranty.
