Name | Elevator Components Full Plastic Compensation Chain ≥1.75m/s |
Product Type: | elevator component |
Availability: | 5000pcs |
Certificates: | ISO9001 |
Warranty-Time: | 1 year |
MOQ: | 1pcs |
Payment: | TT |
Delivery time: | 2-3 days after payment |
Product Description
Full Plastic Elevator Balance Chain Elevator Parts For Compensation Chain
Perfectly combine welded chain with PVC
Good and stable performance
Flexibility, small bending diameters, insulation, durability, aging-resistance, can work under a wide range of temperature
Low noise, recommended for elevator speed over 1.75m/s and less than 3m/s
FUJILF-Elevator full plastic compensation chain
Model number | OD (mm) | Weight(kg/m) | OD (mm) | Min bending Diameter(mm) | Breaking load(≥KN) | Max.Hanglength(m) |
FUJILF-075 | 5.5±0.2 | 1.12±0.2 | 24±2 | 580 | 13.32 | 160 |
FUJILF-100 | 6.3±0.2 | 1.49±0.2 | 27±2 | 600 | 15.63 | 160 |
FUJILF-125 | 7±0.2 | 1.88±0.2 | 30±2 | 600 | 18.18 | 148 |
FUJILF-150 | 7.5±0.2 | 2.24±0.2 | 32±2 | 610 | 21.6 | 130 |
FUJILF-175 | 8±0.2 | 2.60±0.2 | 35±2 | 610 | 23.68 | 145 |
1.The largest elevator parts company integrating warehousing with marketing.
2.Leading supplier and expoter in elevator parts industry.
3.We have various brands elevator parts,such as Kone,Otis,LG Sigma,Schindler,Toshiba,Thyssen and so on .
4.With the excellent after-saled service and warranty.
