| Name | MONADRIVE Elevator Traction Machine MONA450 MRL Conponents |
| Product Type: | elevator component |
| Availability: | 6000pcs |
| Certificates: | ISO9001 |
| Warranty-Time: | 1 year |
| MOQ: | 1pcs |
| Payment: | TT |
| Delivery time: | 2-3 days after payment |
Product Description
MONADRIVE Elevator Traction Machine MONA450 MRL Conponents
MONADRIVE elevator traction machine MONA450, Permanent magnet synchronous gearless traction machine.
The machine can also be used for machine roomless, The above is recommended value of cut angle,it's optional according to practical condition.
Product parameter (specification)
Voltage | 380V | Roping | 2:1 / 4:1 |
EIv.L oad | (1600~3000)kg | Elv.Speed | (0.5~3.0)m/s |
Sheave Diam | 400/450/480/520mm | Duty | S5-40% |
IP Code | IP41 | Max. Static Load | 12000kg |
Ins.Class | F | Weight | 900kg |
Brake | DC110V 2x2.5A | ||
