| Name | Elevator Spare Parts Rope Brake With ACOP |
| Product Type: | elevator parts |
| Availability: | 5000pcs |
| Certificates: | ISO9001 |
| Warranty-Time: | 1 year |
| MOQ: | 1pcs |
| Payment: | TT |
| Delivery time: | 2-3 days after payment |
Product Description
Elevator Rope Gripper Elevator Rope Brake
It's an ACOP(Ascending Car Overspeed Protection) device of elevator cabin
Installation Angle can be adjusted within 0 degree〜42degree
Triggering Mechanism: Mechanical Trigger Or Electrical Trigger
Mechanical rope brake:
1.The braking wire travel:≤8mm
2.Releasing force:RGR-JD-5A:50〜120N;RGR-JD-5AY:20〜50N
3.Tripping distance of the governor:15-25mm
4.Force of the braking wire of governor:≥240N
Electromagnetic rope brake
1.Rated Voltage:DC12V
2.Power:≤50W
3.Current:≤3A
Elevator Rope Gripper | Elevator Rope Brake | ||
Part No. | RGR-JD-5A | RGR-JD-5AY | |
Roping | ||
1:1 | 2:1 | |
Elevator Speed | 0.25~5.0m/s | 0.25~2.5m/s |
Elevator Capacity | 300〜1250kg | 600〜2500kg |
P+Q | 950〜5715kg | 1900〜11430kg |
