| Name | Toshiba Elevator Deflector Sheave 240-360 |
| Product Type: | elevator spareparts |
| Availability: | 5000pcs |
| Certificates: | ISO9001 |
| Warranty-Time: | 1 year |
| MOQ: | 1pcs |
| Payment: | TT |
| Delivery time: | 2-3 days after payment |
Product Description
Nylon Deflector Sheave,
Elevator Pulley Sheave,
Lift Sheave,
Deflective Sheave
1.Nylon types
2.Dia 240-640mm
3.Shaft Length and Diameter as Request
FUJILF elevator deflector sheave Model
| FUJILF-Model | Diameter | Aperture | Number of slots | Rope | Slot Pitch | Thickness | Thickness | Rated load | Bearing |
| D | E | N | d | P | H | h | Q | ||
| 240-01 | φ240 | 80 | 2 | 6.5 | 10 | 42 | 60 | ≤450KG | 6206 |
| 240-02 | 80 | 3 | 6.5 | 10 | 42 | 80 | ≤800KG | 6208 | |
| 240-03 | 90 | 4 | 6.5 | 10 | 52 | 80 | 6210 | ||
| 240-04 | 110 | 5 | 6.5 | 10 | 65 | 80 | ≤1000KG | 6212 | |
| 320-01 | φ320 | 110 | 3 | 8 | 12 | 52 | 80 | ≤630KG | 6212 |
| 320-02 | 13 | ||||||||
| 320-03 | 4 | 8 | 12 | 65 | 80 | ≤800KG | |||
| 320-04 | 13 | ||||||||
| 320-05 | 5 | 8 | 12 | 72 | 80 | ||||
| 320-06 | 13 | ||||||||
| 320-07 | 130 | 6 | 8 | 12 | 90 | 95 | ≤1600KG | 6312 | |
| 320-08 | 13 | ||||||||
| 320-09 | 140 | 7 | 8 | 12 | 104 | 95 | ≤1600KG | 6216 | |
| 320-10 | 13 | ||||||||
| 320-11 | 8 | 8 | 12 | 115 | 120 | ||||
| 320-12 | 13 | ||||||||
| 360-01 | φ360 | 110 | 3 | 8 | 12 | 52 | 80 | ≤630KG | 6212 |
| 360-02 | 3 | 9 | 13 | ||||||
| 360-03 | 4 | 8 | 12 | 65 | 80 | ||||
| 360-04 | 4 | 9 | 13 | ||||||
| 360-05 | 5 | 8 | 12 | 78 | 95 | ≤1000KG | |||
| 360-06 | 5 | 9 | 13 | ||||||
| 360-07 | 130 | 6 | 8 | 12 | 90 | 95 | ≤1600KG | 6312 | |
| 360-08 | 6 | 9 | 13 | ||||||
| 360-09 | 140 | 7 | 8 | 12 | 108 | 95 | ≤1500KG | 6313 | |
| 360-10 | 7 | 9 | 13 | ||||||
| 360-11 | 150 | 8 | 8 | 12 | 115 | 115 | 6314 | ||
| 360-12 | 8 | 9 | 13 |
