| Name | QMA Elevator Inverter Q-7000-IP QMA |
| Product Type: | elevator component |
| Availability: | 6000pcs |
| Certificates: | ISO9001 |
| Warranty-Time: | 1 year |
| MOQ: | 1pcs |
| Payment: | TT |
| Delivery time: | 2-3 days after payment |
Product Description
Q7000-IP Features
1.Type of FC: Adopt IGBT a PWM control
2.Control modes: Current vector control V/F control
3.Support ENCODER independent signal frequency division, signal isolation, open collector output function.
4.Support LINE DRIVE 8192 C/T
5.Ultra alim design is applied for machine room-less elevator
6.Combine current vector control with 32-bit fine-tuning processing and random PWM control
7.Ultra-low noise,with adjustable wave frequency, CF-2 KHz-15 KHz adjustable
8.W/braking unit(≤45kw)
9.W/speed feedback unit
| Synchronous inverter for elevator Q7000-IP | |||||||||||
| FUJILF-model | Three phase 220- 240v 50/60Hz | Three phase 220- 240v 50/60Hz | |||||||||
| Q7000-EC | 0522 | 0722 | 1122 | 1522 | 0744 | 1144 | 1544 | 1844 | 2244 | 3044 | |
| Rated output | Horsepower volume(HP) | 7.5 | 10 | 15 | 20 | 10 | 15 | 20 | 25 | 30 | 40 |
| Rated power(KW) | 5.5 | 7.5 | 11 | 15 | 7.5 | 11 | 15 | 18.5 | 22 | 30 | |
| Rated current(A) | 25 | 33 | 40 | 64 | 18 | 27 | 34 | 41 | 48 | 60 | |
| power supply | Permissible voltage fluctuation | +10%,-15% | |||||||||
| Permissible Frequency fluctuation | ± 5% | ||||||||||
