| Name | ThyssenKrupp Elevator K300 Door Controller IMS-DS20P2B |
| Product Type: | elevator parts |
| Availability: | 5000pcs |
| Certificates: | ISO9001 |
| Warranty-Time: | 1 year |
| MOQ: | 1pcs |
| Payment: | TT |
| Delivery time: | 2-3 days after payment |
Product Description
| Technical Parameters | |
| Items | Electromotor control mode |
| Input Voltage | Single phase AC220V |
| (Allow voltage fluctuation range:+15%~-20%) | |
| Input Frequency | 50/60Hz |
| Max Output Power | 200VA |
| Rated Output Current | 0.7A |
| Control Parameters | |
| Max Speed | 4P:30000r/min |
| Control Range | 1:1500(vector control) |
| Output Frequency | Max 100Hz(vector control) |
| Input Switch Signal | AC/DC 24V~110V |
| Output Switch Signal | Relay:DC24V/AC220V,1A |
| Working Environment | |
| Ambient Temperature | -10~45°C |
| Ambient Humidity | 5~90%RH(Non-condensate) |
| Altitude | Below 3000M |
| Vibration | 2~9Hz:Amplitude=3mm; 9~20Hz:9.8m/S2 |
| Storage Temperature | -25~55°C |
| Storage Humidity | 5~95%RH |
