| Name | CEDES Elevator Sensor GLS 126NT 2NC/NO Spare Parts |
| Product Type: | escalator spareparts |
| Availability: | 5000pcs |
| Certificates: | ISO9001 |
| Warranty-Time: | 1 year |
| MOQ: | 1pcs |
| Payment: | TT |
| Delivery time: | 2-3 days after payment |
Product Description
The GLS 126 NT is a slot-type light barrier which provides millimeter-exact positioning of elevators. Fully sealed with an enclosure rating of IP65, its high light reserve guarantees protection against dirt, dust and smoke.
1.Very high repetitive accuracy of ±0.5 mm
2.Immunity to smoke, dust and dirt
3.Easy mounting
4.Ready to install cable and plug available
5.Can be made to customer‘s specifications
6.Impressive price-perfomance ratio
| GLS | 126 NT | 126 NT-HCL | 126 NT-MV |
| Supply voltage USP | 10 ... 30 VDC | 10 ... 30 VDC | 12 ... 60 VDC |
| Current consumption (without load) | Max. 40 mA | Max. 30 mA | Max. 30 mA |
| Outputs (short-circuit-proof) | PNP/NPN | NPN | PNP |
| Max. output current | 120 mA | 200 mA | 200 mA |
| Output saturation voltage - NPN (IL = 100 mA) - PNP (IL = 100 mA) | < 0.5 V < 2.0 V | < 0.5 V | < 0.5 V |
| Max. capacitive load | 100 nF | 1,000 pF | 10pF |
| Max. response time | 1 ms | 1 ms | 1 ms |
| Max. repetitive accuracy | 0.5 mm | 0.5 mm | 0.5 mm |
| Max. hysteresis | 1 mm | 1 mm | 1 mm |
1.The largest elevator parts company integrating warehousing with marketing.
2.Leading supplier and expoter in elevator parts industry.
3.We have various brands elevator parts,such as Kone,Otis,LG Sigma,Schindler,Toshiba,Thyssen and so on .
4.With the excellent after-saled service and warranty.
