| Name | Elevator Switch Spare Parts AZ-7124 Components |
| Product Type: | escalator spareparts |
| Availability: | 5000pcs |
| Certificates: | ISO9001 |
| Warranty-Time: | 1 year |
| MOQ: | 1pcs |
| Payment: | TT |
| Delivery time: | 2-3 days after payment |
Product Description
Specification
| Rated voltage(V) | Noninductive load(A) | Lnductive load(A) | Lnrush current | |||||
| Resistive load | Inductive | Motor Load | ||||||
| NC | NO | NC | NO | NC | NO | NO | NC | |
| 125VAC | 10 | 3 | 1.5 | 10 | 5 | 2.5 | ||
| 250VAC | 10 | 2.5 | 1.25 | 10 | 3 | 1.5 | ||
| 480VA | 3 | 1.5 | 0.75 | 2.5 | 1.5 | 0.75 | ||
| 8VDC | 10 | 3 | 1.5 | 6 | 6 | 5 | ||
| 14VDC | 10 | 3 | 1.5 | 6 | 6 | 5 | ||
| 30VDC | 8 | 3 | 1.5 | 6 | 5 | 2.5 | ||
| 125VDC | 0.5 | 0.4 | 0.05 | 0.05 | 0.05 | |||
| 250VDC | 0.25 | 0.2 | 0.03 | 0.03 | 0.03 | |||
Operating Characteristics
| Model | AZ-7100 | AZ-7110 | AZ-7310 | AZ-7311 | AZ-7312 | AZ-7120 | AZ-7140 | AZ-7121 | AZ-7141 | AZ-7124 | AZ-7144 | AZ-7166 |
| OF MAX. | 600g | 600g | 600g | 600g | 600g | 150g | 220g | 180g | 240g | 200g | 280g | 120g |
| RF MIN. | 100g | 100g | 100g | 100g | 100g | 40g | 60g | 50g | 80g | 60g | 100g | |
| PT MAX. | 2.0mm | 2.0mm | 2.0mm | 2.0mm | 2.0mm | 13.5mm | 8.5mm | 11.0mm | 6.5mm | 11mm | 6.5mm | 250mm |
| OTMIN. | 0.8mm | 5.0mm | 6.0mm | 6.0mm | 6.0mm | 4.0mm | 2.5mm | 3.0mm | 2.0mm | 3.0mm | 2.0mm | 11mm |
| MD MAX. | 0.8mm | 0.8mm | 0.8mm | 0.8mm | 0.8mm | 3.2mm | 2.0mm | 2.4mm | 1.5mm | 2.4mm | 1.5mm | |
| OP | 30.5±0.8mm | 44±1.2mm | 21.8±1.2mm | 33.3±1.2mm | 33.3±1.2mm | 25±1mm | 25±1mm | 40±1mm | 40±1mm | 50±1.2mm | 50±1.2mm | |
| PF | 35mm | 32mm | 46mm | 56mm |
1.The largest elevator parts company integrating warehousing with marketing.
2.Leading supplier and expoter in elevator parts industry.
3.We have various brands elevator parts,such as Kone,Otis,LG Sigma,Schindler,Toshiba,Thyssen and so on .
4.With the excellent after-saled service and warranty.
